Frigidaire Professional FPGC3077RS Gas Cooktop, 30 inch Exterior Width, 5 Burners, 17,000 BTU Highest Burner, Stainless Steel colour
Frigidaire
FPGC3077RS
Frigidaire Professional FPGC3077RS Gas Cooktop, 30 inch Exterior Width, 5 Burners, 17,000 BTU Highest Burner, Stainless Steel colour
DISCONTINUED
Quick Specs
  • WiFi Enabled: No
  • Power Type: 18000 BTU
  • Burners: 5 burners
Dimensions
W 30in
H 4in
D 22in

Product Dimensions
A - Width
B - Depth
C - Height
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web
at frigidaire.ca.
30"
21-3/4"
4-1/4"
Cutout Dimensions
Width (Min.) / (Max.)
Depth (Min.) / (Max.)
Height
28-1/4" / 28-5/8"
19-3/8" / 19-3/4"
8"

Controls
Surface Type
Sealed Gas Burners
Grates
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Centre Burner (BTU)
Control Location
Knob Colour
Knob Type
Optional Accessories
Griddle
Specifications
Power Supply Connection Location
Gas Supply Connection Location
LP Gas Conversion Kit
Voltage Rating
Amps @ 120 Volts1
Minimum Circuit Required (Amps)
Approved for Electric Single
Wall Oven Combination Installation2
Shipping Weight (Approx.)
PrecisionProTM
Stainless Steel Recessed
Yes
Continuous Cast Iron
w/Black Matte Finish
12,000
750 to 5,000
9,500
9,500
18,200
Centre Front
Stainless
Cast Metal
Included
Right Rear
Right Rear
Included
120V / 60 Hz / 15A
1.0
15
Yes
55 Lbs.

Warranty Support

Warranty support and documents in one place.

Find the manufacturer support line and open your brochure or warranty PDFs below in the floating preview window.

Files

Brochure and warranty documents

1 file
