Cooktop Details
Cooktop Surface Color Black
Cooktop Surface Material Porcelain Coated Steel
Digital Display No
Griddle Included N/A
Heating Element On Indicator Light No
Hot Surface Indicator Light No
Ignition Type Flame-Sensing™ Re-ignition
Number of Open Bays N/A
Details
Automatic Pan Detection No
Cooktop Configuration All Burners
Fuel Type Gas
Installs Over Built-in Oven No
Lp Convertible Yes - Kit Included
Power Outage Compatible Yes
Dimensions
Product Height 7.4375
Carton Height 21
Gross Weight 113
Carton Depth 33.75
Carton Width 34.5
Cutout Width 29.75
Product Depth 27.875
Cutout Depth Min 22.25
Cutout Width Max 29.875
Net Weight 95
Product Width 29.75
Cutout Width Min 29.25
Electrical
208v Compatible No
Power Cord Included Yes
Element/burner Details
Cooktop Element Style Sealed Burner
Cooktop Type Commercial Style
Left Front Element-burner Power 20,000 BTU/14,000 LP
Left Front Element-burner Type Dual-Stacked Burner
Left Rear Element-burner Power 15000 BTU/11000 LP
Left Rear Element-burner Type Professional
Number of Cooking Element-burners 4
Power Boost No
Right Front Element-burner Power 20,000 BTU/14,000 LP
Right Front Element-burner Type Dual-Stacked Burner
Right Rear Element-burner Power 5,000 BTU/3,000 LP
Right Rear Element-burner Type Simmer/Melt
Exterior Details
Knob Color Stainless Steel
Knob Type Metal
Grate Details
Grate Details Dishwasher Safe; Individual; Matte Finish; Porcelain Coated Cast Grates
Number of Grates 4
Ventilation Details
Downdraft Vent No
