Frigidaire Gallery FGIC3066TB Induction Cooktop, 30 inch Exterior Width, 4 Burners, 3,800 Watts Highest Burner Element, Black colour

Product Line Induction Cooktop
Power Type Electric 240v
Size 30"
Installation Type Drop-In
Factory Rayong
Color Black
Installation
Installed Over a Wall Oven Yes
Power Supply Connection Location Right Center
Electrical Specifications
Amps @ 240 Volts 35.1 Amps
Connected Load @ 240V 7.2 kW
Minimum Circuit Required 30 Amps
Voltage Rating 240 V
Certifications and Approvals
ADA Compliant Yes
Cooktop
Cooking Surface Type Smooth
Hot-Surface Indicator Light Yes
Dimensions and Volume
Height 3 5/8"
Width 30 5/8"
Depth 21 3/8"
Safety Certifications and Approvals
UL Listed Yes
Controls
Sabbath Mode No
General Specifications
Frigidaire Fit Promise Yes
Product Weight 57 lbs
Prop 65 Label No
Warranty - Labor 1 Year
Warranty - Parts 1 Year
Cooktop Performance
Right Front Element Burner Size 7"
Left Front Element Burner Size 7"
Left Rear Element Burner Size 6"
Center Rear Element Burner Size 10"
Right Front Element Burner 2,600 Watts
Left Front Element Burner 2,600 Watts
Left Rear Element Burner 2,000 Watts
Center Rear Element Burner 3,800 Watts
Display
Control Location Front
Display Interface Color Red
Display Type Capacitive Touch

Cooktop
Cooking Surface: Black Vitroceramic Glass
Hot-Surface Indicator Light: 4 (integrated in display)
Right Front: 7" 1800/2600 Watts (Induction)
Center Rear: 10" 2500/3800 Watts (Induction)
Left Rear: 6" - 1450/2000 Watts (Induction)
Left Front: 7" 1800/2600 Watts (Induction)

Dimensions: Exterior
Width: 30-5/8"
Depth: 21-3/8"
Height: 2-7/8"

Electrical Specifications
Connected Load @ 240V: 7.2/6.2
Connection Location: Right Rear
Voltage Rating: 240V / 208V 60Hz
Amps @ 240 Volts: 35.0 / 35.1
Min Circuit Required: 30A

General Specifications
Shipping Weight (lbs): 60

Dimensions: Cut-Out
Height: 3-5/8"
Width: 28-1/2" - 29-7/8"
Depth: 19-5/8" - 20-1/2"

Certifications & Approvals
Sabbath Mode: No
Agency Approval(All Brands): UL/cUL
ADA Compliant - All Brands: Yes

Controls
Control Type: Glass-Touch - Slew Pad
Display Type: Digital (Red LED)
Control Location: Center front

Installation Type
Oven Combo Approved: Yes
